Taber Type Abrasion Tester​ Speed Setting Method

Taber Type Abrasion Tester has two types: 1700 single grinding wheel wear tester and 1750 double grinding wheel wear tester. The test speed can be selected as 60 or 72 rpm. The selected speed is used as the default value for each test until the speed is reset. The speed will be displayed on the display.

Shanghai Qianshi Precision Electromechanical Technology Co., Ltd. was established in 2012. It focuses on the research, development, design, and production of textile testing instruments, and provides textile testing instruments and services for academic research units and testing institutions. Shanghai Qianshi is currently one of the most competitive R&D textile testing instrument manufacturers in China. The R&D team is composed of a group of experienced engineers. We are committed to serving customers wholeheartedly and striving to promote technological innovation in textile testing instruments.

Our R&D technical engineer said that when the test machine needs to change the speed, the instrument must be in a stopped state (the display screen must show Stopped in the running state or ground state).

1. Press MENU to display the menu selection (see the menu in the figure below);




2. Press 1 in the menu selection to select change speed;




3. Use the numeric keys to select "1" for 60 rpm and "2" for 72 rpm. The asterisk (*) indicates the current default speed.




4. Press START to start the test.

   The speed of the test machine is in revolutions per minute, and one revolution represents one revolution of the turntable (the factory default speed is 60 rpm).

Applicable standards:

ASTM D1175, ASTM D1044, ASTM D4060, TAPPI T476, ISO 9352, ISO 5470-1, ASTM D3884, JIS K7204, JIS A1453, JIS K6902, JIS L1096, JIS K6964, DIN 52347, DIN 53109, DIN 53754, DIN 53799, etc.

Experimental parameters:

1. Test piece: outer diameter φ108mm, inner diameter φ6mm




2. Grinding wheel: φ2″(MAX.52mm)1/2″(W)




3. Grinding wheel center distance: 63.5mm




4. Grinding wheel and test piece center distance: 37~38mm




5. Rotation speed: 60/72 rpm




6. Load: 250g, 750g, 1000g
