Apparent Bulk Density Meter
The Apparent Bulk Density Meter is designed to determine the bulk density, bulk volume coefficient, and flowability of powders, granules, and fragmented solid materials. It provides standardized measurement solutions based on multiple international methods, enabling accurate evaluation of material packing behavior. The instrument supports different configurations to accommodate fine powders, coarse particles, and compressible materials, ensuring broad applicability across industries.
Application
The Apparent Bulk Density Meter is widely used for testing powders and granular materials in industries such as plastics, chemicals, pharmaceuticals, food, and minerals (e.g., soil and gravel). It is suitable for evaluating loose and tapped bulk density, as well as flow characteristics. The instrument supports material research, quality control, and process optimization by analyzing how materials behave during storage, transport, and handling.
Standards
(1) ASTM D1895 Method A
(2) ASTM D1895 Method B
(3) ASTM D1895 Method C
(4) ISO R60
Parameters
Method A (Fine Particles)
| Item | Specification |
|---|---|
| Measuring Cup Volume | 100 cm³ |
| Funnel Type | V-shaped funnel |
| Funnel Control | Vertical shut-off |
| Net Weight | 4 kg |
| Dimensions (W×D×H) | 18 × 23 × 25 cm |
Method B (Coarse Particles / Granules)
| Item | Specification |
|---|---|
| Measuring Cup Volume | 400 cm³ |
| Funnel Type | V-shaped funnel |
| Funnel Control | Vertical shut-off |
| Net Weight | 9 kg |
| Dimensions (W×D×H) | 24 × 33 × 52 cm |
Method C (Fibers / Flakes / Compressible Materials)
| Item | Specification |
|---|---|
| Measuring Device | Measuring cylinder + plunger |
| Cylinder Volume | 1000 cm³ |
| Plunger Feature | With 1 mm graduations |
| Additional Weight | Lead pellets (total 2300 g) |
| Net Weight | 4 kg |
| Dimensions (W×D×H) | 10 × 10 × 30 cm (max) |
ISO R60 Method
| Item | Specification |
|---|---|
| Measuring Cup Volume | 100 cm³ |
| Funnel Type | Standard funnel (closed in standby mode) |
| Net Weight | 4 kg |
| Dimensions (W×D×H) | 18 × 23 × 25 cm |
Accessories
(1) Measuring cups (100 cm³ / 400 cm³ / 1000 cm³ depending on method)
(2) V-shaped funnel with shut-off mechanism
(3) Measuring cylinder and plunger (Method C)
(4) Lead pellets for compression (Method C)
(5) Instruction manual
(6) Standard accessories for operation and calibration
FAQ
(1) What is the Apparent Bulk Density Meter?
The Apparent Bulk Density Meter is an instrument used to measure the bulk density and flow properties of powders, granules, and other particulate materials.
(2) What is the Apparent Bulk Density Meter used for?
It is used to evaluate material density, packing behavior, and flowability in industries such as plastics, pharmaceuticals, food, and chemicals.
(3) What is the working principle of the Apparent Bulk Density Meter?
It works by allowing materials to fill a container of known volume (or compressing them in specific cases) and calculating density based on mass and volume.
(4) Why is the Apparent Bulk Density Meter important?
It is important because bulk density affects material handling, storage, and processing performance, making it critical for quality control and product consistency.
(5) Which industries use the Apparent Bulk Density Meter?
It is widely used in plastics, chemical, pharmaceutical, food, and mining industries, as well as research and testing laboratories.
