Universal Finger Abrasion Tester
The Universal Finger Abrasion Tester simulates the mechanical and chemical interactions between a human finger and a surface. It evaluates the effects of friction, body oils, sweat, and potential chemical reactions on material surfaces over time. The device uses an electronically controlled piston (artificial finger) to replicate realistic wear patterns, providing precise, reproducible results for product durability and surface performance testing.
Application
(1) Friction simulation between fabric and skin
(2) Material wear and dust accumulation simulation
(3) Leather abrasion resistance testing
(4) High-roughness surface mechanical wear evaluation
(5) Chemical effect simulation from hand cream or sunscreen
(6) Artificial sweat chemical interaction testing
Standards
(1) EC 68-2-70 – Environmental testing, mechanical and chemical durability
(2) EN 60068-2-70 – European standard for mechanical and chemical stress testing
(3) DIN 60068-2-70 – German standard for material abrasion and durability
Parameters
| Parameter | Value |
|---|---|
| Normal Load | 1, 5, 10, or 20 N |
| Number of Cycles | 1 – 100 million |
| Friction Diameter | 1 – 40 mm |
| Power Supply | 110V / 230V |
| Supply Mode | Cyclic |
| Control Method | Electronically controlled linear motor |
| Piston Type | Artificial finger with adjustable pressure |
Features
(1) Flexible system design allowing adjustment of all key test parameters
(2) High-quality, reliable construction for long-term use
(3) Accurate and reproducible testing results
(4) Adjustable settings for various operational conditions
(5) Minimal maintenance requirements
(6) Simulates both mechanical wear and chemical interactions
Accessories
(1) Artificial finger piston assembly
(2) Friction pads of different diameters
(3) Power and control unit
(4) Software for test programming and monitoring
Test Procedures
Mount the artificial finger piston onto the test unit.
Fix the material sample securely on the test platform.
Set the desired load, friction diameter, and cycle count.
Initiate the test program; the linear motor applies precise cyclic motion to simulate wear.
Monitor results via the software; after completion, remove the sample for evaluation of wear, abrasion, or chemical effect.
Maintenance Information
(1) Periodically inspect the artificial finger and friction pads for wear.
(2) Clean the sample platform and friction surfaces after each test.
(3) Check electrical connections and linear motor operation regularly.
(4) Calibrate force and cycle counters annually to maintain accuracy.
(5) Lubricate moving components as recommended by the manufacturer.
FAQ
What is this product?
It is a Universal Finger Abrasion Tester designed to simulate mechanical and chemical interactions between fingers and material surfaces.
What is it used for?
To evaluate material wear, abrasion resistance, and chemical effects from skin, sweat, and topical products.
Why is it important?
Ensures product durability and surface quality under realistic conditions of use.
Which industries is it suitable for?
Automotive interiors, textiles, leather goods, consumer products, cosmetics, and material R&D.
What are the similar products?
Leather abrasion testers, human-skin friction simulators, material wear and durability testers.
