U.V.S Spectrophotometer with Standard Specification G-UVS470
Brand:QINSUN
Model:G-UVS470
Introduction
A UV-Visible Spectrophotometer is an analytical instrument used to measure the light absorption characteristics of substances in the ultraviolet and visible wavelength regions. By detecting the degree of light absorption at different wavelengths, it enables both qualitative and quantitative analysis of substance concentration and composition. The instrument features high sensitivity, fast analysis speed, and easy operation.
Application
(1) For formaldehyde test of different type of fabrics
With shaking bath/ device, reagents, accessories and desktop /laptop computer.
(2) Software to create standard curves and absorbance vs. time graphs and must include wavelength scanning feature.
Must Include:
a 2.1-m (7-ft) detachable cord, dust cover, four-position 10-mm cuvette holder, four glass cuvettes, and two quartz cuvettes
Parameters
Parameter | Specification |
Control System | Microcomputer electronic PC control |
Optics System | Double beam spectrometer with concave holographic grating (1053 lines/mm) |
Product Type | Visible spectroscope |
Wavelength Range | 200–1000 nm |
Bandwidth | 5 nm |
Wavelength Accuracy | ±2 nm |
Photometric Range | 0–125% T |
Transmittance Range | -0.1 to 2.5 |
Absorbance / Concentration Range | 0–1999 concentration |
Detector | Silicon photodiode |
Output Interface | RS-232 |
Path Length | 10 mm (expandable to 100 mm with optional holder) |
Stray Light | < 0.3% T at 340 nm and 400 nm |
Light Source | Tungsten halogen lamp + deuterium lamp |
Power Supply | 230 V, 50 Hz |
Features
(1) Must have multi cell holder option
(2) Conventional UV/Visible analysis
(3) Software-driven DNA/RNA/protein/kinetics analysis
(4) Four-position cuvette holders.
(5) RS-232 or USB ports for connecting directly to a printer or computer.
(6) Must be low profile with a large LED display.
Warranty
One year warranty
