Computerized Flat Knitting Machine G-CF450
Brand:QINSUN
Model:G-CF450
Introduction
A computerized flat knitting machine is a knitting device that uses a computer control system to drive the needle beds for automatic knitting. It can execute complex patterns, structural knitting, and high-precision shaped knitting according to pre-programmed instructions. The machine is characterized by a high degree of automation, high production efficiency, flexible pattern design, and good product consistency, making it an important piece of equipment in the modern knitting industry.
Application
(1) Garment industry: Used for producing sweaters, knitted garments, scarves, hats, and other apparel products.
(2) Home textile products: Used for blankets, cushion covers, and decorative knitted items.
(3) Sports and functional clothing: Used for sportswear, thermal underwear, and functional knitted fabrics.
(4) Industrial knitted products: Used for technical textiles and composite knitted structures.
(5) Fashion and design field: Used for high-end customized knitted products and creative sample development.
Parameters
Parameter | Specification |
Type Details | SV 5/7 Gauge |
Knitting Width | Variable Stroke, Max 45" (114 cm) |
Gauge | Multigauge / Widegauge |
Knitting Speed | Max 1.2 m/sec |
Stitch Density | 120 Levels |
Racking | 1 inch both sides |
Transfer | Simultaneous transfer, front/back any cam direction |
Sinker | Spring type movable sinker |
Setup Device | Take-down comb with special setup needle |
Yarn Cutter | Single unit, 1 cutter, 2 gripper |
Control System | DSCS (Digital Stitch Control System) |
Yarn Carriers | 6 positions |
Controller | Built-in |
Data Input | USB Memory |
Power Supply | Single Phase AC 220–230 V, 1.6 kW |
Weight | 660 kg |
Must be Compatible with external design system like SDS-One-Apex 4 Design system etc.
Warranty
One year warranty
