Sample Printing Machine G-SP308
Brand:QINSUN
Model:G-SP308
Introduction
A sample printing machine is a specialized unit used for prototyping, testing, and small-batch production. These systems—ranging from desktop inkjet coaters to industrial pad and screen printers—allow manufacturers to test print quality, ink adhesion, and designs on actual substrates before committing to large-scale, mass-production runs.
Application
(1) Scrape pulp to run experimental procedure for the operation of inspection equipment.
(2) Imported tablecloth fabric with good elasticity, effect of uniform. Scrape with electromagnets to attract scrape pulp slurry roll a rolling basis.
(3) Magnetic bar scraping force can be free to adjust the slurry, digital display. Scrape pulp free to adjust the speed by frequency conversion, digital display.
(4) Can choose a single scrape pulp, scrape pulp cycle approach.
Key Specification
Parameter | Specification |
Scrape Pulp Itinerary | Freely Adjustable |
Drive System | Direct Motor Ball Screws, Linear Bearings |
Additional Features | With Drainage Channels, Tools, and Chromatic Matching Positioning Device |
Standard Magnetic Bar Quantity | 1 pc |
Standard Magnetic Bar Diameter | 20 mm |
Magnetic Bar Length | 500 mm |
Optional Magnetic Bar Sizes | 10 mm, 15 mm, 20 mm, 25 mm |
Magnetic Bar Stroke | 500 mm |
Standard Fence Quantity | 1 pc |
Standard Fence Size | 640 × 480 mm |
Maximum Fence Size | 650 × 650 mm |
Printing Area | 500 × 400 mm |
Travel Space | 200–500 mm, Stepless Adjustable |
Printing Speed | 0.6–6 m/min, Adjustable |
Power Supply | 220 V, 50 Hz |
Warranty
One year warranty
