Card Punching Machine G-CP202
Brand:QINSUN
Model:G-CP202
Introduction
Card Punching Machine is designed for accurately punching pattern cards used in Jacquard weaving systems. It ensures precise hole placement according to design specifications, enabling smooth and reliable fabric pattern production. With stable performance and easy operation, it is widely used in textile workshops and jacquard card preparation processes.
Technical Specification
Impulse Diameter | Ø 4.5 mm |
Impulse Vertical Hole Distance | 3 mm |
Impulse Horizontal Hole Distance | 12 mm |
Punching / Re-perforating Location Hole Distance | 347 mm (28 harnesses), 275 mm (20 harnesses) |
First Fit Distance (Left Location Hole) | 20.5 mm |
Structure Type | Platform type, suitable for hard-turning operation; continuous line change during punching/re-perforation |
Function | Can duplicate old figure paper (card) to new one, saving labor and time |
Suitable Harnesses | ≤ 28 |
Paper Thickness | 0.22 – 0.25 mm |
Warranty
One year warranty
