LAP FORMER G-LF040
Brand:QINSUN
Model:G-LF040
Introduction
Lap Former is an important piece of equipment in the pre-combing process of the textile industry. It is mainly used to combine, draft, compact and wind the slivers output from the drawing frame into uniform and compact laps for use in the subsequent combing machine.
Parameters
Item | Specification |
1. Doubling | 24/28/32 |
2. Drafting mode | 2 over 3 or 3 over 3 |
3. Pneumatic weight, pressure | 380-550n |
4. Lap speed | 80-120m/min |
5. Output in theory | 350 kg/h |
6. Full lap package Weight (max) | 22kg |
7. Total Draft ratio | Max 1.80 times |
Other | 8. Adopting PLC to control the machine, the touch screen can be displayed the parameter and operation guide; inverter drives the main motor that is easy to set the speed of machine; during the lapping, the speed of main motor is reduced, which reduces the blocking. |
9. Proportional valve for the pressure of sliver, which confirm the right pressure and the pressure can be displayed in the touch screen. | |
10. 28 pcs sensor which monitor the sliver and the machine will be stopped while there is no sliver, broken sliver and sliver stop. | |
11. Feed mode: two sides gantry creel, simple frame and less floor space. | |
12. Cone for UNI-lapper is 96 pcs. | |
13. Electric control: PLC touch screen exhaust upper (with suction motor) With three semi-automatic trolley |
Warranty
One year warranty
