DRAWING FRAME G-DF030
Brand:QINSUN
Model:G-DF030
Introduction
The drawing frame is a key piece of equipment in the pre-spinning process of the textile industry. It is used to combine, draft, mix and homogenize slivers produced by multiple carding machines, improve the fiber arrangement, enhance the quality of the slivers, and provide a stable raw material for subsequent roving and spinning machine production.
Parameters
Item | Specification |
Material | Cotton, manmade fiber, blends, fiber length 10-80 mm |
No. of delivery | 2 (Double coiler) |
Doubling (x) | up to 8 |
No. of feeding end | 6 - 8 |
Draft (x) | 4 - 11 |
Drafting Type | 3 over 3 with pressure bar and guide roller. |
Loading Type | Pendulum arm spring weighting. |
Delivered sliver weight (ktex) | 1.25 – 7 |
Deliver speed | 2.47 - 10m/s (200-600 m/min) |
Feed can diameter | Φ400, Φ500, Φ600 Height: 1100(900) mm. |
Delivery can diameter | Φ300, Φ350, Φ400, Φ500 mm Height: 100(900) mm. |
Max. delivery speed | 1100 m/min |
Control System | The speed of main motor is controlled by inverter. PLC is adopted for controlling system. |
Auto Stop Motion | Photoelectric stop and micro switch stop motion. |
Motors | Main Motor, Can Change Motor, Servo Motor, Suction motor, Cleaning motor. Stop motion Electric stop motion for breakage on top roller & calendar roller; Electric stop motion for choke of sliver at gatherer & coiler tube; Sliver length stop motion actuated by auto reset counter; Electric stop motion for creel part. With Catalogue & operation manual. |
Power | 3 Phase AC, 380V/50HZ |
others | Automatic filter cleaning |
Central drafting system setting without gauges | |
Automatic can changer | |
Empty can feed for up to 3 reserve cans | |
Central lubricating strip | |
Control panel with graphic display |
Warranty
One year warranty
