Vacuum Cleaner Air Performance Testing Equipment
Vacuum Cleaner Air Performance Testing Equipment is a professional testing system designed to evaluate the air performance of vacuum cleaners in accordance with international standards. You can use this equipment to accurately measure and analyze key performance parameters such as voltage, current, input power, power factor, airflow, vacuum pressure, suction power, and overall efficiency. The system integrates European and American standard testing modes, making it suitable for global product verification, R&D validation, and compliance testing.
Applications
Performance verification during vacuum cleaner product development
Type testing and routine inspection in quality control laboratories
Certification testing for export-oriented products
Comparative performance analysis between different models
Standards
IEC 60312-1: Vacuum cleaners for household use – Methods for measuring the performance – Part 1: Dry vacuum cleaners
IEC 62885-2: Surface cleaning appliances – Part 2: Dry vacuum cleaners for household or similar use – Methods for measuring the performance
ASTM F431-21: Standard Test Method for Measuring the Air Performance Characteristics of Vacuum Cleaners
ASTM F558-17: Standard Test Method for Measuring Air Performance Characteristics of Upright, Canister, Handheld, Stick, and Robotic Vacuum Cleaners
Technical Parameters
| Item | Specification |
|---|---|
| Test Stations | Single station (Euro standard / US standard) |
| Pressure Chamber Dimensions | Euro standard: 500×500×500 mm; US standard: 457.2×457.2×254 mm |
| Test Modes | Euro standard, US standard |
| Drive Motor | Servo motor |
| Flow Meter | Range: 0.5–5 m³/min; Accuracy: ±0.05% / 0.075% |
| Vacuum Gauge | Range: -50–0 Kpa; Accuracy: ±0.075% / ±0.05% |
| Orifice Plate Sizes (Euro & US standard) | 63.5, 57.2, 50.8, 44.5, 38.1, 34.9, 31.7, 28.6, 25.4, 22.2, 19.0, 15.8, 12.7, 9.5, 6.3 mm |
| Power Supply & Current Detection | AC: 0–250V; DC: 0–60V; Current detection range: 0–30A |
| Equipment Power | 220V, 2.5KW |
| Equipment Dimensions | 1850×1150×1750 mm |
Features
You can switch freely between European and American standard testing modes within one system
Industrial computer control with a 17-inch display provides clear visualization of test items and data
Automatic data acquisition and calculation reduce manual intervention and human error
Real-time monitoring of electrical and air performance parameters
Automatic generation and storage of test reports and characteristic curves via USB
High measurement accuracy ensures reliable and repeatable test results
Suitable for both laboratory testing and production-line quality verification
Accessoriess
(1) European standard equalization chamber
(2) American standard equalization chamber
(3) Rotary orifice plate set (American standard)
(4) Industrial control computer with display
(5) Power and signal connection cables
FAQ
1. Can one system test both European and American standard vacuum cleaners?
Yes. You can select either European or American standard testing modes directly on the control interface without changing the core system.
2. What parameters can you measure during a test?
You can measure voltage, current, input power, power factor, airflow, vacuum pressure, suction power, and efficiency.
3. Is the equipment suitable for certification testing?
Yes. The system is designed according to IEC and American standards and is suitable for certification, type testing, and conformity assessment.
4. How are test results stored and exported?
Test data, reports, and performance curves are automatically recorded and can be exported via USB.
5. Does the system require frequent calibration?
Calibration frequency depends on usage and laboratory requirements, but regular verification of flowmeters and vacuum gauges is recommended to maintain accuracy
