Surface Flammability Tester
Application
The Surface Flammability Tester is used to evaluate the burning behavior of textile fabrics with pile surfaces. It is suitable for quality control, laboratory testing, and compliance verification for textiles in apparel, home furnishings, carpets, and industrial fabrics.
Standards
GB/T 8745-2001 – Textile Combustion Performance: Fabric Surface Burning Time Measurement (China)
ISO 10047:1993 – Textiles – Determination of Burning Behavior of Fabrics
ASTM D1230 – Standard Test Method for Flammability of Apparel Textiles
CFR 16 Part 1610 – Flammability of Clothing Textiles (USA)
EN ISO 6940 – Textiles – Determination of Burning Behavior
NFPA 701 – Standard Methods of Fire Tests for Flame Propagation of Textiles and Films
JIS L1091 – Testing Methods for Burning Behavior of Textiles (Japan)
Parameters
| Parameter | Specification |
|---|---|
| Sample Holder Size | 150 mm × 75 mm |
| Ignition Time | 0–99.99 s, adjustable |
| Flame Height | 40 ± 2 mm |
| Distance between Ignition and Specimen Holder | 15 mm |
| Ignition Method | Electric wire ignition |
| Gas Type | Industrial butane, propane, or butane/propane mixture |
| Display | Digital, automatic recording of burning time |
| Power Supply | AC 220V, 50Hz |
Advantages
Accurate and reproducible measurements of fabric surface flammability.
Adjustable ignition time and flame height to meet multiple standards.
Digital display allows automatic recording, reducing operator errors.
Compact and user-friendly design suitable for laboratory or production use.
Compatible with various combustible gases for flexible testing.
FAQ
What is the Surface Flammability Tester?
It is a device used to measure the combustion time and flame propagation of textile fabrics under controlled conditions.
Why is surface flammability testing important?
Ensures that textile products meet safety regulations and reduce fire hazards in consumer products.
What types of fabrics can be tested?
Pile fabrics, carpets, upholstery, clothing textiles, and industrial fabrics.
How is the sample tested?
The fabric is clamped in the sample holder; an electric ignition source is applied at a fixed distance, and the burning time and flame height are measured automatically.
Which international and domestic standards does it comply with?
Complies with GB/T 8745-2001, ISO 10047:1993, ASTM D1230, CFR 16 Part 1610, EN ISO 6940, NFPA 701, and JIS L1091.
