Steel Hook Bending Tester Machine
1. Product Introduction & Applications
The Steel Hook Bending Tester Machine is designed to evaluate the bending resistance and durability of steel hooks. It performs standardized bending tests to ensure hooks meet quality and safety requirements.
Applications:
Steel hooks in industrial, construction, and hardware applications
Quality control of hooks for load-bearing and safety-critical use
Inspection of hook material integrity after repeated bending
Test Principle:
The hook is inserted into the fixture and rotated 180° around a cylindrical column with a diameter of φ10 mm. After bending, the hook surface is inspected for cracks, fractures, or deformation to determine the product’s bending resistance and overall quality.
2. Conformity Standards
GB 28011 — Steel hook bending resistance test
QB/T 1812 — Hook mechanical testing
QB/T 1813 — Hook performance evaluation
BS 5131 — British standard for hook testing
GB/T 28011-2021 Section 7.8 — Section 7.8: Hook bending test
3. Technical Parameters
| Parameter | Specification |
|---|---|
| Drive Mode | Motorized |
| Bending Angle | 180° |
| Center Column Diameter | φ10 mm |
| Power Supply | Single-phase AC 220V, 50/60 Hz |
| Dimensions (W × D × H) | Approx. 400 × 400 × 500 mm |
| Weight | Approx. 30 kg |
4. FAQ
Q1: What types of hooks can be tested?
A1: The tester is suitable for steel hooks used in industrial, construction, and load-bearing applications.
Q2: How is bending resistance evaluated?
A2: Hooks are rotated 180° around a φ10 mm column, and the surface is inspected for cracks, fractures, or deformation.
Q3: What is the power requirement?
A3: Single-phase AC 220V, 50/60 Hz.
Q4: Does it comply with international standards?
A4: Yes, the machine meets GB 28011, QB/T 1812, QB/T 1813, and BS 5131 standards.
Q5: Is the machine portable?
A5: Yes, with a compact size (400 × 400 × 500 mm) and weight of approximately 30 kg, it is suitable for laboratory or workshop use.
