Steam Generator 100-V2
The 100-V2 Steam Generator is a dedicated thermal shock (steam injection) testing system designed to meet automotive OEM standards. It delivers stable and repeatable high-temperature steam for thermal shock evaluation of automotive components. With controlled steam flow and dynamic pressure, the 100-V2 Steam Generator provides reliable data for durability and performance verification under extreme thermal conditions.
Application
Thermal shock (steam injection) testing of automotive components such as lamps, sensors, connectors, and electronic housings
Evaluation of material resistance to rapid temperature changes and moisture exposure
Validation of sealing performance and structural integrity under high-temperature steam conditions
Durability testing of plastic, rubber, and composite components in automotive environments
Quality control and product validation in automotive OEM and supplier laboratories
Standard:
The 100-V2 steam generator meets the requirements of Ford FLTM BI 107-05, GMW15919 and FCA LP-463PB-64-01 thermal shock test specifications.
Thermal shock test requirements:
Test Innovation Equipment is one of the only approved automotive thermal shock (steam injection) test manufacturers.
If you are new to thermal shock testing, you may find that an overview of thermal shock testing helps you become more familiar with the various OEM thermal shock testing methods.
Parameters
| Module | Parameter | Specification |
|---|---|---|
| Steam Generator | Water Flow Rate | 2.7 ± 0.1 L/min |
| Steam Dynamic Pressure | 37.9 ± 1.9 kPa | |
| Heating Method | Gas / Electric adjustable burner | |
| Tubular Nozzle | Inner Diameter | 12.5 ± 0.3 mm |
| Length | ≥100 mm | |
| Material | Non-corrosive material | |
| Hose | Type | High temperature / high pressure resistant |
| Dynamic Head Clamp | Measurement Pressure | 37.9 ± 1.9 kPa |
| Measurement Distance | 25 mm from nozzle | |
| Tube Bore Diameter | 4.7 mm | |
| General | Model | 100-V2 |
| Power Supply | AC 220V / 50Hz |
FAQ
(1) What is the purpose of the 100-V2 Steam Generator in thermal shock testing?
The 100-V2 Steam Generator is designed for steam injection thermal shock testing according to Ford FLTM BI 107-05 and GMW15919. It evaluates how automotive components respond to rapid temperature changes and high humidity conditions. The test helps identify material degradation, sealing failure, and structural weaknesses under extreme environments.
(2) How is steam dynamic pressure controlled and measured?
The 100-V2 Steam Generator controls steam output through regulated water flow and heating. Dynamic pressure is measured using the DHF-1 clamp at a distance of 25 mm from the nozzle, with a target value of 37.9 ± 1.9 kPa. This ensures compliance with OEM test specifications and consistent test conditions.
(3) What types of components can be tested with the 100-V2 Steam Generator?
The system is suitable for testing automotive lamps, connectors, sensors, electronic housings, and sealing components. It is widely used to verify resistance to thermal shock, moisture ingress, and mechanical stress under steam exposure conditions defined in automotive standards.
(4) Why is nozzle specification important in thermal shock testing?
The tubular nozzle of the 100-V2 Steam Generator must meet strict dimensional requirements (12.5 ± 0.3 mm ID, ≥100 mm length) to ensure consistent steam flow and pressure distribution. This directly affects test repeatability and compliance with standards such as FCA LP-463PB-64-01.
(5) What should be considered when selecting a steam generator for thermal shock testing?
Key factors include compliance with OEM standards, stable steam output, precise pressure control, and durable components. The 100-V2 Steam Generator meets these requirements, providing accurate simulation of thermal shock conditions and ensuring reliable testing for automotive applications.
