Textile and Fabric Water Vapour Permeability Tester

Textile and Fabric Water Vapour Permeability Tester

Vapour permeation rate tester Product Information:

The device is a constant temperature and humidity moisture permeability test device, which is suitable for sportswear and other requirements of the waterproof, moisture permeability of both the fabric, as well as plastic film, processed paper and other moisture-resistant packaging materials for the purpose of moisture permeability evaluation test.

Place a quantity of anhydrous calcium chloride into the empty moisture-permeable cup. Then install the sample and seal the moisture-permeable cup with the sample. The moisture permeable cup of the sealed package was placed in a laboratory for fixed temperature and humidity conditions for a period of time, and the moisture permeability of the sample was calculated by increasing the weight of anhydrous calcium chloride, thereby determining the moisture permeability of the sample.


Water Vapour Permeability Testing Apparatus Technical parameters:

1.Working pattern :computer control, LCD English menu operation, testing environment monitoring

2.Testing box temp. Control range: room-temperature:~45°C;distinguishability:0.1°C

3.Testing box temp. Control accuracy:±0.5°C

4.Testing box humidity control: 40%RH~95%RH±2%RH

5.Testing box humidification:≥300ml/h

6.Testing time:1min~999h59min

7.Circulating air speed:0.02~1.5m/s


Instrument features:

1, apply a variety of standards and measurement methods.

2. Rotary sample holder, adjustable speed, uniform test than fixed sample holder.

3, the wind speed is adjustable, the use of imported wind speed sensor calibration, speed accuracy and stability.

4, temperature and humidity control using PID algorithm, small fluctuations, effectively prevent temperature and humidity overshoot; with temperature and humidity calibration function, can well avoid the sensor bias caused by long-term use.

5, high-precision temperature and humidity sensors, test data stability, high precision.

6, SCM control, color touch screen operation, modular design, temperature and humidity digital settings, intelligent control, real-time display of temperature and humidity and time.

7. Input parameters in the color touch screen to calculate WVT, WVP and PV values.

8, the instrument is equipped with PC software, can record temperature and humidity curve, easy to calculate and print a large number of data reports.

fabric water vapor permeability &penetrability tester







Note:QINSUN always been committed to innovation and improve product performance and functionality, based on the reasons, the product specifications will be changed accordingly. The above without prior notice, the Company reserves the right to amend the final.
