Dispensing Tunnel Oven
The Dispensing Tunnel Oven is designed for automated heating, curing, and drying processes after dispensing operations. It features programmable control and error-proofing functions, ensuring stable and efficient production. This equipment is widely used in industries such as electronics, silicone rubber, hardware, automotive, and molding.
Application
This tunnel oven is suitable for:
(1) Glue dispensing curing in electronic products.
(2) Silicone and rubber component drying.
(3) Automotive parts bonding and curing.
(4) Hardware and mold heating processes.
(5) Continuous production lines requiring controlled curing.
Standards
The equipment can be designed according to:
(1) GB/T 10067 Industrial Heating Equipment Technical Requirements
(2) GB 5226 Electrical Safety of Machinery
(3) General industrial oven standards
Parameters
| Item | Specification |
|---|---|
| Equipment Type | Dispensing Tunnel Oven |
| Product Size | 1300 × 300 mm |
| Fixture Size | 1360 × 375 × 210 mm |
| Furnace Height | 330 mm |
| Baking Time | 15 minutes |
| Temperature Setting | 60℃ (adjustable) |
| Temperature Range | Ambient ~ 200℃ |
| Temperature Accuracy | ±2℃ |
| Platform Length | 1500 mm (inlet & outlet) |
| Production Capacity | 300 pcs / 7 hours |
| Load Weight | Product 2 kg / Fixture 20 kg |
Features
(1) Suitable for dispensing curing and drying processes.
(2) Programmable control with parameter storage.
(3) Stable conveying without shifting or vibration.
(4) Adjustable temperature and speed settings.
(5) Equipped with error-proofing and protection functions.
(6) Supports continuous automated production.
