Coating & Potting Tunnel Oven G-CH153S
The Coating & Potting Tunnel Oven G-CH153S is specially designed for curing processes after coating and potting applications in the electronics industry. The oven provides precise low-temperature control, stable conveyor operation, and independent multi-channel transportation to ensure uniform curing quality and improve production efficiency.
Equipped with a Siemens PLC + HMI control system, OMRON PID temperature controllers, and three independent conveyor lanes, the Coating & Potting Tunnel Oven enables flexible production management for different product models and curing requirements. It is widely used for electronic components, wire harnesses, control modules, and other products requiring reliable coating or potting curing processes.
Application
The Coating & Potting Tunnel Oven is suitable for low-temperature drying and curing applications, including:
Electronic Components
PCB assemblies
Electronic control modules
Sensors
Power supply components
Coating Processes
Protective coating curing
Conformal coating drying
Insulation coating baking
Potting Applications
Silicone potting curing
Epoxy resin curing
Electronic encapsulation processes
Other Precision Industries
Wire harness assemblies
Automotive electronic components
Industrial control products
Technical Specifications
| Item | Specification |
|---|---|
| Equipment Model | G-CH153S |
| Equipment Type | Coating & Potting Tunnel Oven |
| Application Industry | Coating and potting industry |
| Power Supply | AC380V 3Φ 50Hz |
| Power Capacity | 60KVA |
| External Dimension | W2300mm × L7000mm × H800/1800mm |
| Conveyor Width | 500mm × 3 lanes |
| Conveyor Height | 800±40mm |
| Conveyor Structure | Three independent conveyor lanes |
| Heating Zone Length | 6 meters |
| Temperature Zones | 3 independent control zones |
| Working Temperature | Stable 45–50℃ |
| Temperature Setting Range | 40–80℃ |
| Temperature Uniformity | ≤±2℃ |
| Temperature Control | OMRON PID Controller |
| Temperature Testing | Six-point temperature measurement |
| Conveyor Speed | 0–6.0m/min adjustable |
| Conveyor Adjustment | Independent frequency control for each lane |
| Control System | Siemens PLC + HMI |
| Working Modes | Automatic / Manual / Cleaning |
| Inner Chamber Material | SUS304 stainless steel |
| Outer Material | 1.5mm Q235 carbon steel |
| Surface Treatment | High-temperature powder coating |
| Exterior Color | RAL 7035 Light Grey |
Features
(1) Designed for Coating and Potting Processes
Specially developed for electronic products after coating and potting, providing stable curing conditions and reducing defects caused by uneven heating.
(2) Precise Low Temperature Control
The oven maintains stable working temperatures between 45℃ and 50℃, suitable for sensitive electronic materials.
(3) Three Independent Conveyor Channels
Three conveyor lanes operate independently, allowing flexible production scheduling and improved production efficiency.
(4) Uniform Temperature Distribution
Three heating zones are independently controlled by OMRON PID temperature controllers, achieving temperature uniformity within ±2℃.
(5) Intelligent PLC Control System
The Siemens PLC and HMI system provide automatic operation, manual adjustment, and cleaning modes for different production requirements.
(6) Automatic Product Tracking Function
The HMI displays real-time product quantity in each lane, helping operators monitor production status.
(7) Flexible Conveyor Speed Adjustment
Each conveyor lane supports independent frequency conversion speed control from 0–6.0m/min.
(8) Safety and Easy Maintenance Design
The lifting doors, openable side panels, and rotary control screen provide convenient operation and maintenance.
