Ceramic Tunnel Oven Drying Line
The Ceramic Tunnel Oven Drying Line is an industrial-scale continuous thermal processing system widely used for continuous drying, dehydration, curing, and sintering of various industrial products.With a continuous conveyor structure and precise temperature control system, the equipment enables stable and uniform heating performance, making it an essential production unit for ceramic manufacturing, electronic materials, new energy industries, and other high-temperature processing applications.
Applications
Ceramic Products
Used for drying and initial firing of daily-use ceramics, architectural ceramics, and artistic ceramics.
Electronic Components
Used for baking electronic ceramics, multilayer ceramic capacitors (MLCC), and ceramic substrates.
New Energy Materials
Used for continuous drying of lithium battery cathode and anode materials, catalysts, and other functional materials.
Hardware and Glass Products
Used for moisture removal of metal components, annealing of glass products, and curing of surface coatings.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | Room temperature to 400℃ / 1050℃ (Customized according to heating elements and refractory materials) |
| Temperature Control Accuracy | ±1℃ (Programmable PID intelligent microcomputer temperature control) |
| Furnace Length | 6m – 60m (Customized according to production capacity requirements) |
| Conveyor Width | 300mm – 1500mm (Optional stainless steel mesh belt, Teflon mesh belt, chain conveyor, roller conveyor, etc.) |
| Heating Methods | Electric heating / Natural gas heating / LPG heating |
| Conveyor Speed | 0.1 – 5 m/min (Variable frequency stepless speed regulation) |
Features
High Efficiency and Energy Saving
The equipment combines heavy-duty refractory materials with advanced composite insulation layers, significantly reducing heat loss and improving thermal efficiency.
Precise Temperature Control
Adopts independent multi-zone temperature control technology to ensure uniform temperature distribution inside the furnace and stable heating curves.
Continuous Production
Equipped with a fully automatic conveying system, supporting 24-hour continuous production operation for large-scale manufacturing.
Intelligent and Environmentally Friendly
Integrated with exhaust gas discharge systems and waste heat recovery devices, reducing energy consumption and supporting low-carbon production.
Safe and Durable Operation
Equipped with over-temperature alarm and conveyor overload protection. Electrical components adopt high-quality industrial brands to ensure long-term stable operation.
