Textile Drying Time Tester
The Textile Drying Time Tester is designed to measure the drying time of textiles, solids, powders, granules, gels, and non-volatile liquids. It provides precise and reliable measurement of moisture content and drying kinetics, supporting quality control and research applications in textile and material science.
Application
This tester is suitable for measuring drying characteristics of:
Woven and knitted fabrics
Nonwoven textiles
Powdered chemicals and pigments
Granular materials
Gels and pastes
Non-volatile liquids used in coatings or adhesives
Standards
The Textile Drying Time Tester complies with the following national and international standards:
(1) AATCC 199-2013 – Standard Test Method for Drying Time of Textiles (USA)
(2) ISO 17617 – Textiles – Determination of Drying Time
(3) ASTM D2824 – Standard Test Method for Drying of Textile Materials
(4) GB/T 19939 – Textile Drying Time Measurement (China)
(5) JIS L 1922 – Determination of Drying Rate of Textiles (Japan)
Parameters
| Parameter | Specification |
|---|---|
| Weighing precision | 0.001 g |
| Weighing range | 124 g |
| Temperature resolution | 0.1 °C |
| Moisture content readability | 0.01% |
| Moisture content range (MC%) | 0.00% – 100.00% |
| Solid content range (DC%) | 0.00% – 100.00% |
| Test temperature | Room temperature – 200 °C |
| Temperature response time | ≤ 3 s |
| Sample pan diameter | 90 mm |
| Heating chamber height | 24.5 mm |
| Heating method | Halogen lamp |
| Power supply | AC 220 V, 50 Hz, 500 W |
| Dimensions (L×W×H) | 315 × 210 × 205 mm |
| Weight | Approx. 9.5 kg |
Features
Ten independent testing stations with real-time monitoring
Automatic independent weighing system for each station
High-precision 0.001 g moisture measurement, with automatic external calibration using standard weights
Test reports exportable to Excel and Word; supports project categorization and customized report formats
Data can be integrated with ERP systems for paperless operation
Key components made of imported stainless steel or alloy steel
Optimized structural design for precise sample positioning
Automatic calculation and generation of drying results
Powerful database management for long-term data storage and analysis
Accessories
(1) Main unit – 1 pc
(2) Product certificate – 1 pc
(3) User manual – 1 pc
(4) Delivery note – 1 pc
(5) Acceptance form – 1 pc
(6) Product brochure – 1 pc
Test Procedures
Place the sample in the designated sample pan at the testing station.
Set the desired drying temperature and time parameters.
Start the testing program; the halogen lamp will heat the sample automatically.
The independent weighing system monitors moisture loss in real-time.
After the test, results are automatically calculated and displayed.
Export data to Excel or Word for further analysis.
Calibrate stations periodically using standard weights to maintain accuracy.
Maintenance Information
Clean sample pans after each test to avoid residue build-up.
Inspect halogen lamps periodically and replace if intensity decreases.
Ensure weighing sensors are free of dust and debris.
Verify calibration with standard weights regularly.
Avoid exposure to moisture or corrosive environments for long-term storage.
FAQ
What is this product?
A precision instrument for measuring drying time and moisture loss in textiles and other materials.
What is it used for?
To determine drying performance and moisture content changes for textiles, powders, gels, and non-volatile liquids.
Why is it important?
Ensures material quality, optimizes drying processes, and supports R&D and quality control.
Which industries is it suitable for?
Textile manufacturing, chemical processing, coatings, adhesives, research laboratories.
What types of materials can be tested?
Fabrics, powders, granules, gels, pastes, and non-volatile liquids.
