Pedal Performance Endurance Test Bench

This test bench can test the car pedals. The test results can be used to decide whether the products are qualified, and maintained for statistics, analysis, storage and printing.

Application

The Pedal Performance Endurance Test Bench is widely used in:

Automotive Manufacturing: For quality control of pedal assemblies before assembly into vehicles.

R&D and Design Testing: Helps engineers optimize clutch, brake, and accelerator pedal design for safety, comfort, and performance.

Aftermarket Parts Evaluation: Verifies the durability of replacement pedals and aftermarket components.

Automotive Component Suppliers: Ensures compliance with international and domestic standards for pedal assemblies.

Safety and Reliability Testing: Evaluates longitudinal and lateral displacement, stiffness, anti-torsion, and load endurance under repeated cycling conditions.

This system supports multiple pedal types and assembly variations, providing a versatile solution for comprehensive pedal evaluation.

Standards

QC/T788-2007 The performance requirement of the car pedal device and the test method of the bench

QHMAC 103[1].143-201-2005 clutch pedal

QHMAC 103[1].143-202-2005 brake pedal

QHMAC 103[1].141-201-2005 accelerator pedal

Test Items

· Longitudinal displacement, lateral displacement, stiffness, intensity, anti-torsion performance test for different kinds of pedal assemblies.

· Clutch pedal durability test.

· Accelerator pedal durability test.

· Brake pedal durability test.

· Different kinds of pedal assemblies durability test.

· 20 degree of force durability test for accelerator pedal and brake pedal.

Technical Parameters
