Non-standard Industrial Oven (Vacuum Reflow Oven)
The Non-standard Industrial Oven (Vacuum Reflow Oven) is a customized continuous thermal processing system designed to meet specific process requirements. It integrates vacuum technology, multi-zone heating, and hot air circulation to deliver stable and uniform thermal performance. Equipped with a stainless steel mesh belt conveyor and cleanroom-compatible structure, the system ensures smooth, contamination-free transport and high process reliability for advanced manufacturing applications.
Applications
This non-standard oven is widely used in industries requiring high precision and reliability:
Electronics: PCB, SMT reflow soldering, component curing
Semiconductor: chip packaging and thermal processing
New energy: battery module soldering and heat treatment
Automotive electronics: high-reliability soldering processes
Precision manufacturing: vacuum heat processing applications
Technical Parameters
| Parameter | Specification |
|---|---|
| Power Supply | AC380V, 3 Phase, 50Hz |
| Total Length | 6000 mm |
| Heating Zone Length | 5000 mm |
| Temperature Range | 40℃ – 350℃ (Typical ≤180℃) |
| Temperature Uniformity | ±3℃ (excluding inlet/outlet) |
| Conveyor Speed | 0.3 – 2.0 m/min (adjustable) |
| Typical Speed | 0.8 m/min |
| Conveyor Type | SUS stainless steel mesh belt / Teflon belt |
| Belt Width | 1010 mm |
| Heating Method | Medium-wave quartz heating tubes |
| Exhaust Volume | Max. 10.0 m³/min |
| Exhaust Pipe | ∮80 mm × 6 |
| Temperature Control Accuracy | ±0.3% FS |
| Vacuum Requirement | Vacuum achieved within 10 seconds |
| Control System | Siemens PLC + Touchscreen |
| Temperature Recording | 6-point recorder (USB export) |
| Surface Temperature | ≤45℃ (except specific areas) |
| Cleanliness Level | Class 100 |
Features
Custom-engineered Design: Fully tailored to specific product size, process flow, and capacity requirements
Vacuum Reflow Capability: Effectively reduces voids in solder joints and improves bonding reliability
High-precision Temperature Control: Multi-zone PID control ensures stable and consistent heating
Cleanroom-ready Structure: Stainless steel chamber and low-particle design meet Class 100 standards
Efficient Heating System: Quartz heating tubes provide fast heating and high thermal efficiency
Stable Conveying System: Smooth operation without vibration, jamming, or product damage
Advanced Automation: Siemens PLC with touchscreen interface, supports MES integration
Comprehensive Safety Protection: Includes phase sequence protection, overload protection, emergency stop, and over-temperature protection
Easy Maintenance: Motorized top cover allows convenient inspection and servicing
