Double-station Taber abrasion tester

Double-station Taber abrasion tester

The Taber Abrasion Tester is used for wear and abrasion resistance testing. It measures a specimen's wear resistance and other wear properties, such as mass loss, thickness loss, and light transmittance change, by subjecting it to friction with a specified abrasive material under a constant load and velocity. The abrasion wheel is pre-ground using standard methods, ensuring highly consistent test results. The instrument's high repeatability of test data helps manufacturers effectively control production and inspect their products.

Compliant Standards

IS09352 Determination of Abrasion Resistance of Plastics by Abrasive Wheel Method

IS05470 Determination of Abrasion Resistance of Rubber or Plastic Coated Fabrics

IS07784 Determination of Abrasion Resistance of Paints and Varnishes - Part 2: Rotating Abrasive Rubber Wheel Method

ASTM D1044 Test Method for Abrasion Resistance of Transparent Plastic Surfaces

ASTM D3884 Test Method for Abrasion Resistance of Fabrics

ASTM D4060 Standard Test Method for Abrasion Resistance of Organic Coatings by Abraser

GB/T 5137.1 Test Methods for Automotive Safety Glass - Part 1: Mechanical Tests

GB/T 2726 Leather - Physical and Mechanical Testing - Determination of Abrasion Resistance

DIN 53109 Tests on Paper and Paperboard - Determination of Abrasiveness by Tribology

Technical Parameters

Test Mode: Automatic

Test Speed: 1-85 RPM

Empty Arm Force: 250g

Specimen Diameter: 113mm

Specimen Surface Diameter: 100mm

Load Range: 125g, 250g, 500g, 750g, 1000g, 1250g

Test Sample Thickness: Adjustable

Weight: 18.2kg

Power Supply: 220V

Dimensions: 450mm*350mm*400mm

Test Cycles: Up to 999,999

Advantages

1. Highly Simulated Actual Friction Environment: The CS-6054B Wear Tester closely simulates the friction and wear environment experienced by materials during actual use. By precisely controlling parameters such as the wear wheel material, pressure, and rotational speed, it can reproduce a variety of complex wear scenarios, making test results more valuable. This simulation capability helps companies accurately assess the wear resistance of materials during product development and production, avoiding product quality issues caused by insufficient wear resistance.

2. High-Precision Measurement: The tester boasts high precision in measuring parameters, from measuring mass loss, detecting thickness change, to assessing the degree of surface wear, all with pinpoint accuracy. This high-precision measurement ensures the accuracy and reliability of test results, providing strong support for companies' quality control efforts.

3. Excellent Repeatability: Thanks to its standardized testing process and stable instrument performance, the CS-6054B Wear Tester's test results are highly repeatable. This means that test results remain consistent across different times and by different operators. This repeatability is crucial for companies' quality control and product development. 4. Wide Application: The TABER abrasion tester is suitable for testing the abrasion resistance of a variety of materials, including fabric, paper, paint, plywood, leather, floor tiles, glass, natural rubber, and artificial flooring. This makes it widely applicable in a wide range of industries, including textiles, leather, paint, plastics, electronics, and electrical appliances. Through testing, companies can select high-quality raw materials and processing techniques, ensuring products with excellent wear resistance, thereby improving their market competitiveness and customer satisfaction.

5. Easy and Safe Operation: The CS-6054B abrasion tester is designed with user convenience in mind. All buttons are carefully designed for easy operation, and a one-button emergency stop function ensures safe operation. Furthermore, the tester features a clear display and intuitive user interface, allowing users to easily understand test progress and results.
