Whole Shoes Flexing Tester

Whole Shoes Flexing Tester

Skype / Email



Shoes Flexing Tester determine its flexibility resistance of shoes or shoes sole through reciprocating flexing movements under the specified angle and frequency.


Application:

The whole shoes flexing tester is used to test finished shoes, like sports shoes, casual shoes, work shoes etc. And determine its flexibility resistance or indicating the cracks of shoe or shoe sole through reciprocating flexing movements under the specified angle and frequency.


Feature:

1. Shoe Flexing Testing Machine Equipped with acrylic protective cover, which make sure safe operation and low noise.

2. Heel fixture using linear slide for smooth movement with little resistance.

3. Freely set running times and machine automatically stop after test finished.


Parameter:

Test sample:Test 4 samples simultaneously

Control method:Touch screen control

Bending angle:0~ 90° (adjustable)

Test speed:0°~50°, adjustable speed range: 60~230 rpm、50°~90°, adjustable speed range: 60~140 rpm

Counter:0-99,999,99 (7 digits)

Power:1∮AC 220V 50/60HZ  3A

Dimension(W×D×H):95 x 76 x70cm

Weights:223kg


Standards:

SATRA TM92,

ISO 24266 Method A





Note:QINSUN is very in place for textile testing and quality control,we have our own textile testing lab. Our textile testing equipment and testing methods are in the leading position in the industry. We have passed the textile testing certification and iso textile testing standards issued by a number of testing,We can provide textile testing equipment pdf manual. Sufficient inventory, big discounts, limited time promotion, Order now!
