AAtcc Color Fastness to Washing Tester

AAtcc Color Fastness to Washing Tester

Skype / Email


Washing Fastness Tester Product Information:

For conducting colorfastness to wash, dry cleaning, fulling, detergency and other tests at temperatures up to 95°C, also including the colorfastness of dye.Washing Fastness Tester is an ideal machine for assessing fastness to washing, dry cleaning of coloured textile samples.

The two separated cylinders equip with independent control panels respectively, able to conduct the two tests with different temperature independently and simultaneously.

Control system consists of electronic switch for light touch, liquid crystal display Menu without mechanical contact, safe and reliable for operators. Stable of sample frame rotation is convenient for mounting washing containers.


Fastness to Washing Tester Technical Parameters:

1.Test container station: (12+12)×2;

2.Rotating speed: 40±2 rpm;

3.Control mode: CNC, independently control the temperature and time of two test cylinders simultaneously, procedure could be set arbitrarily;

4.Dimension of sampling container: 1200±10ml and 550±10ml;

5.Function of Inching rotation for each cylinders;

6.Function of automatic alarm as the test finished;

7.Material: stainless steel of 316;

8.Rapidly changing sample containers;

9.The temperature control is up to 98℃;

10.Temperature accuracy: -/+0.3℃;

Testing Standards:

ISO 105 C01 C02 C03 C04 C05 C06 C08 D01, BS 1006 C01 C02 C03 C04 C05, AATCC 28 61 86 132 151 190, NEXT TM2 3 5, M&S C4 C5 C10A P3B, GB/T 3921 5711, FTMS 191-5610

Accessories and Consumables:

1.The machine of Double-Cylinder Launder-Ometer

2.Stainless steel sampling cups of 550ml: 16

3.Stainless steel sampling cups of 1200ml: 16

4.Stainless Steel Balls for washing test: 2000

5.Container seals for stainless steel sampling cups of 550ml: pack of 20

aatcc color fastness to washing tester



Note:QINSUN is very in place for textile testing and quality control,we have our own textile testing lab. Our textile testing equipment and testing methods are in the leading position in the industry. We have passed the textile testing certification and iso textile testing standards issued by a number of testing,We can provide textile testing equipment pdf manual. Sufficient inventory, big discounts, limited time promotion, Order now!
