Material Drying and Curing Furnace
The Material Drying and Curing Furnace is a high-efficiency industrial thermal processing equipment designed for removing moisture, volatile substances, and promoting chemical reactions such as the curing of coatings, adhesives, and resins.The equipment adopts an advanced temperature control system and hot air circulation technology to ensure uniform temperature distribution inside the furnace. It is widely used in industrial processes including drying, dehydration, heat setting, and high-temperature curing.
Applications
1. Surface Treatment
Used for drying and curing after:
Painting
Powder coating
Spray coating processes
2. Electronics and Electrical Industry
Applied for:
Transformer varnish baking
PCB board baking
Adhesive dispensing curing
Electronic component aging tests
3. Plastic and Rubber Industry
Used for:
Drying plastic materials before secondary injection molding
Rubber product vulcanization processes
4. Hardware and Machinery Industry
Used for:
Stress relief annealing of metal components
Moisture removal after cleaning processes
5. Composite Materials Industry
Suitable for:
Heat pressing of carbon fiber materials
Atmospheric pressure curing of resin-based composites
Product Parameters
| Parameter Item | Technical Specification |
|---|---|
| Temperature Range | Room Temperature – 300℃ / 500℃ (Customized according to process requirements) |
| Temperature Control Accuracy | ±1℃ |
| Temperature Uniformity | ±2.5% (Full-load test) |
| Heating Method | Electric Heating / Gas Heating / Steam Heating |
| Air Duct Structure | Horizontal air circulation / Vertical air circulation / Multi-directional combined circulation |
| Outer Shell Material | High-quality cold-rolled steel plate with powder coating |
| Inner Chamber Material | SUS304 stainless steel plate / Galvanized steel plate |
| Control System | PLC touchscreen / PID intelligent digital temperature controller |
Features
1. Precise Temperature Control
The equipment adopts a microcomputer intelligent temperature control system, providing stable temperature regulation and preventing over-drying or overheating of materials.
2. Uniform Heating Performance
Equipped with a specially designed powerful hot air circulation system, ensuring no dead zones inside the furnace and minimizing temperature differences.
3. Energy Efficient Operation
Uses a high-density aluminum silicate insulation layer to reduce heat loss, significantly improving energy efficiency and reducing operating costs.
4. Safe and Reliable Operation
Equipped with multiple safety protection functions, including:
Over-temperature alarm
Exhaust and smoke discharge system
Phase-loss protection
to ensure safe production.
5. Customized Design Support
The furnace structure can be customized according to material characteristics and production requirements, including:
Trolley-type furnace
Conveyor mesh belt furnace
Other customized configurations
