Endodontic File Torque Testing Instrument
The Endodontic File Torque Testing Instrument is specially designed for torsional performance testing of endodontic files. It measures torsional strength, maximum torque, maximum torsion angle, and bending strength. Torque-angle curves are displayed in real time. The professional software automatically calculates peak force and torsion angle and supports test report generation in curve, Excel, and text formats.
Application
(1) Torsional strength testing of endodontic files
(2) Maximum torque testing
(3) Maximum torsion angle testing
(4) Bending strength testing
(5) Complete cycle testing of specimens
(6) Individual parameter testing
Parameters
| Parameter | Specification |
|---|---|
| Machine Type | Horizontal |
| Maximum Test Force | ±200–500 N·mm |
| Force Resolution | 0.01 N·mm |
| Accurate Measurement Range | 1%FS–100%FS |
| Testing Machine Grade | Class 1 / Class 0.5 |
| Torsion Speed | 0.1–720°/min, stepless |
| Torsion Angle | Unlimited |
| Test Space | 0–200 mm, adjustable |
| Power Supply | 220 V, 50 Hz |
| Protection | Overcurrent, overvoltage, and overload protection |
Features
(1) Dedicated for Endodontic Files – Designed specifically for torsional performance evaluation of endodontic files.
(2) Real-Time Curve Display – Displays torque-angle curves during testing.
(3) Automatic Data Calculation – Automatically calculates peak values and torsion angle data.
(4) Flexible Test Programs – Test procedures can be adjusted according to actual testing requirements.
(5) Multiple Report Formats – Supports curve, Excel, and text-based test reports.
(6) Computer-Controlled Operation – Controls the testing process and performs data acquisition and processing automatically.
