Ink Drying Tester
The Ink Drying Tester is designed and manufactured according to the Chinese Light Industry Standard QB562 “Methods for Testing Ink Drying”. It provides a reliable method to determine the drying time of inks. The drying time is defined as the time required for an ink sample, with a specified amount of siccative added, to prevent adhesion of tracing paper under a defined pressure, expressed in hours. Testing is conducted by comparing the standard reference sample with the test sample. The instrument uses microcontroller control and LCD display for test parameters.
Application
(1) Determination of ink drying time for gravure, flexographic, or offset inks
(2) Quality control of ink formulations in R&D laboratories
(3) Comparison of standard ink vs. modified ink drying performance
(4) Laboratory evaluation of printing substrates and coatings
Standards
(1) QB 562-1991 Method for Testing Ink Drying Time
(2) ISO 2836:2016 Graphic technology — Determination of drying properties of printing inks
(3) ASTM D1640-18 Standard Test Method for Drying, Curing, or Film Formation of Organic Coatings at Room Temperature
(4) GB/T 12951 Printing inks — Determination of drying time
Parameters
| Parameter | Value |
|---|---|
| Power Supply | 220V, 50Hz |
| Pressure Roller Moving Speed | 2 mm/rev |
| Pressure Roller Weight | 100 g |
| Test Duration | 5–20 hours |
| Total Revolutions | 120 revolutions |
| Dimensions (L×W×H) | 500×200×220 mm |
| Weight | 17 kg |
Features
(1) Microcontroller-controlled operation with LCD display of test parameters
(2) Automatic rotation of drum for standardized testing
(3) Consistent pressure application along the circumference of the drum
(4) Converts the number of adhesion marks on tracing paper into ink drying time
(5) Compact and lightweight design for laboratory use
(6) Simple operation and high reproducibility
Accessories
(1) Standard reference ink samples
(2) Test ink samples
(3) Tracing paper and adhesive tape for fixation
(4) Pressure roller
(5) Instruction manual
Test Procedures
Fix the standard reference sample, test ink sample, and tracing paper onto the drum using adhesive tape.
Set the drum rotation speed and start the rotation.
Apply the pressure roller along the drum’s axis at a constant proportion.
Count the number of adhesion marks on the tracing paper.
Calculate the drying time of the test ink based on the observed adhesion marks.
Compare with standard sample to evaluate performance.
Maintenance Information
(1) Clean the drum, pressure roller, and tracing paper holder after each test to prevent residue buildup.
(2) Check for smooth rotation and proper alignment of the pressure roller regularly.
(3) Avoid exposure to moisture or corrosive substances.
(4) Inspect the electronic control system and LCD display periodically for faults.
(5) Calibrate speed and pressure rollers annually to ensure accurate results.
FAQ
What is this product?
It is an Ink Drying Tester for measuring the drying time of inks in a laboratory environment.
What is it used for?
To determine the drying time of inks under controlled conditions and evaluate ink formulation quality.
Why is it important?
Ensures accurate assessment of ink drying properties before full-scale printing, reducing waste and improving production efficiency.
Which industries is it suitable for?
Printing industry, ink R&D laboratories, coating and packaging materials testing.
What are the similar products?
Ink proofing machines, drying time testers for coatings, and flexographic/gravure laboratory ink evaluation units.
